SHELL CONSTRUCTION:

• High strength fiberglass molding
• 1/2” of structural thickness in reinforced areas
• UV stabilized coating
• Acrylic adhesive bonding between shell halves
• Polyurethane sealant

FAN:

• Air foil shaped blades for increased air flow
• Blades are made of a glass fiber reinforced polymer
• Direct drive
• Factory set for maximum air movement

MOTOR:

• TEFC construction
• Mounted on a stainless steel frame
• Supported on reinforced fiberglass shell area
• Mounted to shell with stainless steel fasteners

INLET LOUVERS:

• PVC construction
• Easily removed for cleaning
• Vertical orientation to eliminate ‘splash out’
• Directs air flow at proper angle for even distribution
• Helps prevent air-born debris from entering cell

DISTRIBUTION HEADER:

• Non-ferrous PVC ‘cross’ construction
• Stationary
• Computer designed spray pattern
• Large orifice spray heads
• PVC spray heads
• Drift eliminator prevents over spray and water loss

WET DECK:

• Stacked honeycomb pattern maximizes water and air flow for greater cooling efficiency
• PVC construction

INSPECTION COVERS:

• Easily removed
• Seamless gasket sealing
• Allows for inspection of cell interior and replacement of wet deck

WARRANTIES:

• 10 year shell warranty
• 5 year motor/fan warranty

OPTIONS

FAN STARTER KIT:

• Motor starter contactor
• Motor overload relay
• Nema 1 enclosure
• Fan thermostat

SIDE OUTLET:

• PVC flange
• Factory installed

BASIN FLOAT VALVE:

• Mechanical float and valve
• 1/2” supply connection
• Factory or field installed

TOWER STAND:

• 10’ corner post design with cross bracing
• Ladder and railing attachments
